Ratio: 1:1 Maximum Flow: 90-g.p.m. (340.7-l.p.m.) Displacement per cycle: 0.64-Gallons (2.42-Liters) Air Inlet: (Female) 1/2 - 14 N.P.T.F. - 1 Fluid Inlet/Outlet: 1-1/2 11-1/2 N.P.T.F. - 1 Rp 1-1/2 (1-1/2 - 11 BSP parallel) Max. operating pressure: 120-psi (8.3-bar) Suspended solids max. dia.: 1/4-inch (6.4-mm) Weight: lbs (kg) 666150-X-C (aluminum) 51.5 (23.4) 666151-X-C (stainless steel) 84.5 (38.3) 666152-X-C (cast iron) 79.5 (36.1) Note: Add 23-lbs (10.4-kg) for cast iron a
Features
Mobility - Compact, rugged design allows for easy mobility
Efficiency - Motor design delivers optimum air efficiency
Reliability - ARO's patented 'Unbalanced' air valve ensures no-stall operation
Versatility - Available in aluminum, cast iron or stainless steel to withstand tough chemical applications
Environmentally Sound - Bolted construction for leak-free fluid handling
Serviceability - Easy access to ball checks and fluid caps for maintenance and repairs
Accessories
66084-1 Air Line Connection Kit: contains Piggyback Filter / Regulator, pipe nipple & 5’ section of hose
67174-15 Screened Inlet Kit
62133 Wall Mount
66975 Cycle Counter Kit
637118-C Air Section Service Kit
637124-XX Fluid Section Service Kit
Pump Casing Materials
Aluminum
Cast Iron
Stainless Steel
Diaphragm Materials
Viton
PTFE w/ Santoprene backer
Hytrel
Santoprene
Nitrile
Neoprene
E.P.R.
