Hot selling models P8/SSAPP/BNS/BN/BN/0014 P8/SSAPP/EPS/EP/EP/0014 P8/SSAPP/TNU/TF/STF/0014 P8/SSAPP/TSU/TF/STF/0070 P8/SSAPP/TWS/TF/STF/0014 P8/SSAPP/TWS/TF/STF/0070 P8/SSAPP/ZSS/FS/FS/0070 P8/SSAPP/ZWS/WF/WF P8/SSAPP/ZWS/WF/WF/0014 P8/SSSPP/BNS/BN/BN P8/SSSPP/BNS/BN/BN/0014 P8/SSSPP/TNU/TF/STF P8/SSSPP/TWS/TF/STF/0070 P8/WWAPP/BNS/BN/BN P8/WWAPP/NES/NE/NE/0014 P8/WWAPP/ZWS/WF/WF/0014 P8/AAAPP/BNS/BN/BN P8/AAAPP/BNS/BN/BN/0014 P8/AAAPP/EPS/EP/EP/0014 P8/AAAPP/NES/NE/NE/0014
1/2" FNPT
51 mm (2")
51 mm (2")
NPT/BSPT (Threaded)
Rubber –6.9 m (22.7') Dry, 8.6 m (28.4') Wet
TPE – 6.7 m (22.1') Dry, 8.6 m (28.4') Wet
Full-Stroke PTFE – 6.7 m (22.1') Dry, 9.0 m (29.5') Wet
Reduced-Stroke PTFE – 4.6 m (15.0') Dry, 9.5 m (31.0') Wet
Ultra-Flex™ – 4.9 m (16.0') Dry, 8.8 m (29.0') Wet
Note: Dimensions vary by material and connection. For additional information, please refer to the P8 Metal Manual.
Note: Additional performance curves can be found in the P8 Metal Manual.
1/2" FNPT
51 mm (2")
51 mm (2")
NPT/BSPT (Threaded)
Rubber – 623 lpm (165 gpm)
TPE – 630 lpm (166 gpm)
Full-Stroke PTFE – 618 lpm (163 gpm)
Reduced-Stroke PTFE – 496 lpm (131 gpm)
Ultra-Flex™ – 526 lpm (139 gpm)
8.6 bar (125 psi)
6.4 mm (1/4'')
Rubber –6.9 m (22.7') Dry, 8.6 m (28.4') Wet
TPE – 6.7 m (22.1') Dry, 8.6 m (28.4') Wet
Full-Stroke PTFE – 6.7 m (22.1') Dry, 9.0 m (29.5') Wet
Reduced-Stroke PTFE – 4.6 m (15.0') Dry, 9.5 m (31.0') Wet
Ultra-Flex™ – 4.9 m (16.0') Dry, 8.8 m (29.0') Wet
Rubber – 2.6 L (0.70 gal)
TPE – 2.8 L (0.75 gal)
Full-Stroke PTFE – 2.6 L (0.70 gal)
Reduced-Stroke PTFE – 1.67 L (0.44 gal)
Ultra-Flex™ – 2.12 L (0.56 gal)
| Material | Ship Weight |
|---|---|
| Aluminum | 32 kg (70 lb) |
| Stainless Steel | 51 kg (112 lb) |
| Cast Iron | 47 kg (104 lb) |
| Alloy C | 52 kg (114 lb) |
| Description | Material |
|---|---|
| Center Block | Polypropylene |
| Air Valve | Polypropylene |
| Air Chamber | Aluminum, PTFE-Coated, Nickel-Plated, Stainless Steel, Halar-Coated Aluminum |
Rubber – 623 lpm (165 gpm)
TPE – 630 lpm (166 gpm)
Full-Stroke PTFE – 618 lpm (163 gpm)
Reduced-Stroke PTFE – 496 lpm (131 gpm)
Ultra-Flex™ – 526 lpm (139 gpm)
8.6 bar (125 psi)
6.4 mm (1/4'')
Rubber – 2.6 L (0.70 gal)
TPE – 2.8 L (0.75 gal)
Full-Stroke PTFE – 2.6 L (0.70 gal)
Reduced-Stroke PTFE – 1.67 L (0.44 gal)
Ultra-Flex™ – 2.12 L (0.56 gal)
