Hot selling models XPS1520/AAAAA/BNS/BN/BN XPS1520/AAAAA/BNS/BN/BN/0014 XPS1520/AAAAA/TWS/TF/STF/0014 XPS1520/AAAAA/ZGS/BN/BN XPS1520/AAAAA/ZWS/WF/WF XPS1520/AAAAA/ZWS/WF/WF/0014 XPS1520/SSAAA/TWS/TF/STF XPS1520/SSAAA/TWS/TF/STF/0014 XPS1520/SSAAA/ZWS/WF/WF XPS1520/SSAAA/ZWS/WF/WF/0014 XPS1520/WWAAA/TWS/TF/MTF XPS1520/WWAAA/TWS/TF/MTF/0014 XPS1520/WWAAA/ZSS/FS/FS XPS1520/WWAAA/ZWS/WF/WF/0014 XPS1530/AAAAA/BNS/BN/BN XPS1530/AAAAA/EPS/EP/EP XPS1530/AAAAA/EPS/EP/EP/0504 XPS1530/AA
3/4" FNPT
76 mm (3")
76 mm (3")
NPT/BSPT (Threaded)
DIN/ANSI (Flanged)
Rubber – 5.1 L (1.35 gal)
EZ-Install TPE – 5.4 L (1.43 gal)
Full-Stroke PTFE – 5.0 L (1.32 gal)
Full-Stroke PTFE (Ductile Iron) – 4.8 L (1.26 gal)
Note: Dimensions vary by material and connection. For additional information, please refer to the P1520/PS1530 Metal Manual.
Note: Additional performance curves can be found in the PS1520/PS1530 Metal Manual.
3/4" FNPT
76 mm (3")
76 mm (3")
NPT/BSPT (Threaded)
DIN/ANSI (Flanged)
Rubber – 1026 lpm (271 gpm)
EZ-Install TPE – 1026 lpm (271 gpm)
Full-Stroke PTFE – 992 lpm (262 gpm)
Full-Stroke PTFE (Ductile Iron) – 874 lpm (231 gpm)
8.6 bar (125 psi)
12.7 mm (1/2")
Rubber – 7.2 m (23.8') Dry, 9.7 m (31.8’) Wet
EZ-Install TPE – 6.4 m (21.1') Dry, 9.7 m (31.8’) Wet
Full-Stroke PTFE – 6.2 m (20.2') Dry, 8.6 m (28.4') Wet
Full-Stroke PTFE (Ductile Iron) – 5.9 m (19.5') Dry, 9.7 m (31.7') Wet
Rubber – 5.1 L (1.35 gal)
EZ-Install TPE – 5.4 L (1.43 gal)
Full-Stroke PTFE – 5.0 L (1.32 gal)
Full-Stroke PTFE (Ductile Iron) – 4.8 L (1.26 gal)
| Material | Ship Weight |
|---|---|
| Aluminum | 69 kg (152 lb) (PS1520) 101 kg (223 lb) (PS1530) |
| Stainless Steel | 126 kg (278 lb) (PS1520) 137 kg (300 lb) (PS1530) |
| Ductile Iron | 114 kg (251 lb) (PS1520) 124 kg (272 lb) (PS1530) |
| Alloy C | 153 kg (337 lb) (PS1530) |
| Description | Material |
|---|---|
| Center Section | Aluminum, Polypropylene, Stainless Steel |
| Air Valve | Aluminum, Polypropylene, Anodized Aluminum, Stainless Steel |
| Air Chamber | Aluminum, Stainless Steel |
Rubber – 1,026 lpm (271 gpm)
EZ-Install TPE – 1,026 lpm (271 gpm)
Full-Stroke PTFE – 992 lpm (262 gpm)
Full-Stroke PTFE (Ductile Iron) – 874 lpm (231 gpm)
8.6 bar (125 psi)
12.7 mm (1/2")
Rubber – 7.2 m (23.8’) Dry, 9.7 m (31.8’) Wet
EZ-Install TPE – 6.4 m (21.1') Dry, 9.7 m (31.8’) Wet
Full-Stroke PTFE – 6.2 m (20.2') Dry, 8.6 m (28.4') Wet
Full-Stroke PTFE (Ductile Iron) – 5.9 m (19.5') Dry, 9.7 m (31.7') Wet
