Hot selling models XPS820/AAAAA/NES/NE/NE XPS820/AAAAA/TWS/TF/ATF XPS820/AAAAA/VTS/VT/VT XPS820/AAAAA/ZWS/WF/WF XPS820/AAAAA/ZWS/WF/WF/0014 XPS820/SSAAA/TWS/TF/STF XPS820/SSAAA/TWS/TF/STF/0014 XPS820/SSAAA/ZWS/WF/WF/0014 XPS820/SSSSS/TWS/TF/STF/0014 XPS830/AAAAA/BNS/BN/BN XPS830/AAAAA/TWS/TF/ATF XPS830/AAAAA/VTS/VT/VT XPS830/AAAAA/ZPS/PU/PU XPS830/AAAAA/ZPS/PU/PU/0504 XPS830/AAAAA/ZPS/TF/PU/0504 XPS830/AAAAA/ZWS/WF/WF XPS830/SSAAA/BNS/BN/BN XPS830/SSAAA/EPS/EP/EP XPS830/SSAAA/
3/4" FNPT
51 mm (2")
51 mm (2")
NPT/BSPT (Threaded)
DIN/ANSI (Flanged)
Rubber – 7.1 m (23.3') Dry, 9.0 m (29.5') Wet
EZ-Install TPE – 7.0 m (23.1') Dry, 9.0 m (29.5') Wet
Full-Stroke PTFE – 6.6 m (21.8') Dry, 9.0 m (29.5') Wet
Note: Dimensions vary by material and connection. For additional information, please refer to the PS820/PS830 Metal Manual.
Note: Additional performance curves can be found in the PS820/PS830 Metal Manual.
3/4" FNPT
51 mm (2")
51 mm (2")
NPT/BSPT (Threaded)
DIN/ANSI (Flanged)
Rubber – 685 lpm (181 gpm)
EZ-Install TPE – 668 lpm (176 gpm)
Full-Stroke PTFE – 655 lpm (173 gpm)
8.6 bar (125 psi)
6.4 mm (1/4")
Rubber – 7.1 m (23.3') Dry, 9.0 m (29.5') Wet
EZ-Install TPE – 7.0 m (23.1') Dry, 9.0 m (29.5') Wet
Full-Stroke PTFE – 6.6 m (21.8') Dry, 9.0 m (29.5') Wet
Rubber – 2.8 L (0.73 gal)
EZ-Install TPE – 2.6 L (0.70 gal)
Full-Stroke PTFE – 2.5 L (0.65 gal)
| MATERIAL | SHIP WEIGHT |
|---|---|
| Aluminum | 47 kg (104 lb) (PS820) 54 kg (118 lb) (PS830) |
| Stainless Steel | 73 kg (161 lb) (PS820) 81 kg (178 lb) (PS830) |
| Ductile Iron | 71 kg (156 lb) (PS820) 82 kg (181 lb) (PS830) |
| Alloy C | 91 kg (200 lb) (PS830) |
| DESCRIPTION | MATERIAL |
|---|---|
| Center Section | Aluminum, Polypropylene, Stainless Steel |
| Air Valve | Aluminum, Anodized Aluminum, Polypropylene, Stainless Steel |
| Air Chamber | Aluminum, Stainless Steel |
Rubber – 685 lpm (181 gpm)
EZ-Install TPE – 668 lpm (176 gpm)
Full-Stroke PTFE – 655 lpm (173 gpm)
8.6 bar (125 psi)
6.4 mm (1/4")
Rubber – 2.8 L (0.73 gal)
EZ-Install TPE – 2.6 L (0.70 gal)
Full-Stroke PTFE – 2.5 L (0.65 gal)
