1/2" Pro-Flo SHIFT FDA Series Clamp-On Metal Diaphragm Pumps

Dimensions

Note: Dimensions vary by material and connection. For additional information, please refer to the PS1 Metal Manual.

Flow Curve – TPE-Fitted

Note: Additional performance curves can be found in the PS1 Metal Manual.

AIR INLET

• 1/2" FNPT

LIQUID INLET

• 25 mm (1”)

LIQUID DISCHARGE

• 25 mm (1”)

CONNECTION TYPE

• Tri-Clamp®

MAX FLOW RATE

• Rubber – 60.2 lpm (15.9 gpm)

• TPE – 60.2 lpm (15.9 gpm)

• PTFE – 59.8 lpm (15.8 gpm)

MAX PRESSURE

• 8.6 bar (125 psi)

MAX DIAMETER SOLIDS

• 1.6 mm (1/16”)

MAX SUCTION LIFT CAPABILITY

• Rubber – 5.9 m Dry (19.3’), 9.8 m Wet (32.3’)

• TPE – 5.7 m Dry (18.7’), 8.3 m Wet (27.2’)

• PTFE – 4.3 m Dry (14.2’), 9.7 m Wet (31.7’)

DISPLACEMENT PER STROKE *

• Rubber – 0.10 L (0.026 gal)

• TPE – 0.10 L (0.026 gal)

• PTFE – 0.10 L (0.026 gal)

* 1 cycle = 2 strokes

Wetted Housings

Non-wetted Housings
