Hot selling models P200/KKPPP/TNU/TF/KTV P200/KKPPP/TSU/TF/KTV P200/KKPPP/TWS/TF/KTV P200/KKPPP/TWS/TF/KTV/0504 P200/KKPPP/WFS/TF/KTV P200/KKPPP/WFS/WF/KTV P200/KKPPP/WFS/WF/KWF P200/KKPPP/WFS/WF/KWF/0504 P200/PKPPP/BNS/BN/PBN P200/PKPPP/EPS/EP/PTV P200/PKPPP/EPS/EP/PTV/0504 P200/PKPPP/TNU/TF/KTV P200/PKPPP/TNU/TF/PTV P200/PKPPP/TNU/TF/PTV/0504 P200/PKPPP/TSU/TF/PTV P200/PKPPP/TWS/TF/PTV P200/PKPPP/TWS/TF/PTV/0504 P200/PKPPP/VTS/VT/PTV P200/PKPPP/WFS/WF/PWF P200/PKPPP/WFS/WF/
1/4" FNPT
25 mm (1")
25 mm (1")
DIN/ANSI (Flanged)
Rubber – 3.6 m (11.9') Dry, 9.1 m (30.0') Wet
TPE – 3.5 m (11.4') Dry, 9.8 m (32.0') Wet
Full-Stroke PTFE – 3.5 m (11.4') Dry, 8.6 m (28.4') Wet
Reduced-Stroke PTFE – 2.4 m (7.9') Dry, 9.4 m (31.0') Wet
Note: Dimensions vary by material and connection. For additional information, please refer to the P200 Plastic Manual.
Note: Additional performance curves can be found in the P200 Plastic Manual.
1/4" FNPT
25 mm (1")
25 mm (1")
DIN/ANSI (Flanged)
Rubber – 220 lpm (58 gpm)
TPE – 216 lpm (57 gpm)
Full-Stroke PTFE – 195 lpm (51.4 gpm)
Reduced-Stroke PTFE – 174 lpm (46 gpm)
8.6 bar (125 psi) on Polypropylene and PVDF pumps
4.76 mm (3/16")
Rubber – 3.6 m (11.9') Dry, 9.1 m (30.0') Wet
TPE – 3.5 m (11.4') Dry, 9.8 m (32.0') Wet
Full-Stroke PTFE – 3.5 m (11.4') Dry, 8.6 m (28.4') Wet
Reduced-Stroke PTFE – 2.4 m (7.9') Dry, 9.4 m (31.0') Wet
Rubber – 0.32 L (0.09 gal)
TPE – 0.33 L (0.09 gal)
Full-Stroke PTFE – 0.5 L (0.13 gal)
Reduced-Stroke PTFE – 0.22 L (0.06 gal)
Rubber – 220 lpm (58 gpm)
TPE – 216 lpm (57 gpm)
Full-Stroke PTFE – 195 lpm (51.4 gpm)
Reduced-Stroke PTFE – 174 lpm (46 gpm)
8.6 bar (125 psi) on Polypropylene and PVDF pumps
4.76 mm (3/16")
Rubber – 0.32 L (0.09 gal)
TPE – 0.33 L (0.09 gal)
Full-Stroke PTFE – 0.5 L (0.13 gal)
Reduced-Stroke PTFE – 0.22 L (0.06 gal)
