1/4" FNPT
13 mm (1/2")
13 mm (1/2")
NPT/BSPT (Threaded)
Rubber – 5.2 m (17.0') Dry, 8.7 m (28.4') Wet
TPE – 5.2 m (17.0') Dry, 5.5 m (18.0') Wet
PTFE – 4.5 m (14.7') Dry, 9.3 (30.6') Wet
Note: Dimensions vary by material and connection. For additional information, please refer to the P100 Plastic Manual.
Note: Additional performance curves can be found in the P100 Plastic Manual.
1/4" FNPT
13 mm (1/2")
13 mm (1/2")
NPT/BSPT (Threaded)
Rubber – 56 lpm (14.8 gpm)
TPE – 58.7 lpm (15.5 gpm)
PTFE – 57 lpm (15 gpm)
8.6 bar (125 psi)
1.6 mm (1/16")
Rubber – 5.2 m (17.0') Dry, 8.7 m (28.4') Wet
TPE – 5.2 m (17.0') Dry, 5.5 m (18.0') Wet
PTFE – 4.5 m (14.7') Dry, 9.3 (30.6') Wet
Rubber – 0.10 L (0.027 gal)
TPE – 0.11 L (0.029 gal)
PTFE – 0.10 L (0.027 gal)
| Material | Ship Weight |
|---|---|
| Polypropylene / Conductive Polypropylene | 4 kg (8 lb) |
| PVDF / Conductive PVDF | 5 kg (10 lb) |
| Description | Material |
|---|---|
| Center Section | Polypropylene, Conductive Polypropylene |
| Air Valve | Polypropylene, Conductive Polypropylene |
Rubber – 56 lpm (14.8 gpm)
TPE – 58.7 lpm (15.5 gpm)
PTFE – 57 lpm (15 gpm)
8.6 bar (125 psi)
1.6 mm (1/16")
Rubber – 0.10 L (0.027 gal)
TPE – 0.11 L (0.029 gal)
PTFE – 0.10 L (0.027 gal)
