Hot selling models T8/AAAAB/BNS/BN/BN/0014 T8/AAAAB/BNS/BN/BN/0030 T8/AAAAB/NES/NE/NE/0014 T8/AAAAB/NEU/NE/NE/0014 T8/AAAAB/TWS/TF/ATF/0014 T8/AAAAB/VTS/VT/VT T8/AAAAB/VTS/VT/VT/0014 T8/AAAAB/VTU/VT/VT T8/AAAAB/ZWS/WF/WF/0014 T8/SSAAB/TWS/TF/STF/0014 T8/WWAAB/ZWS/WF/WF/0014 T8/WWAPB/BNS/BN/BN/0014 TZ8/AAAAB/BNS/BN/BN/0014 TZ8/AAAAB/NES/NE/NE/0014 TZ8/AAAAB/TNU/TF/ATF TZ8/AAAAB/TNU/TF/ATF/0014 TZ8/AAAAB/TWS/TF/ATF/0014 TZ8/AAAAB/ZWS/WF/WF/0014 TZ8/SSAAB/BNS/BN/BN/0014 TZ8/SSA
3/4" FNPT
51 mm (2")
51 mm (2")
NPT/BSPT (Threaded)
Rubber – 6.4 m(21')Dry, 9.5 m (31') Wet
TPE – 6.1 m (20') Dry, 9.5 m (31') Wet
PTFE – 3.7 m (12') Dry, 9.5 m (31') Wet
Note: Dimensions vary by material and connection. For additional information, please refer to the T8 Metal Manual.
Note: Additional performance curves can be found in the T8 Metal Manual.
3/4" FNPT
51 mm (2")
51 mm (2")
NPT/BSPT (Threaded)
Rubber – 617 lpm (163 gpm)
TPE – 613 lpm (162 gpm)
PTFE – 534 lpm (141 gpm)
8.6 bar (125 psi)
6.4 mm (1/4'')
Rubber – 6.4 m (21') Dry, 9.5 m (31') Wet
TPE – 6.1 m (20') Dry, 9.5 m (31') Wet
PTFE – 3.7 m (12') Dry, 9.5 m (31') Wet
Rubber – 2.69 L (0.71 gal)
TPE – 2.8 L (0.74 gal)
PTFE – 1.51 L (0.40 gal)
| MATERIAL | SHIP WEIGHT |
|---|---|
| Aluminum | 33 kg (72 lb) |
| Cast Iron | 52 kg (114 lb) |
| DESCRIPTION | MATERIAL |
|---|---|
| Center Section | Aluminum, Polypropylene |
| Air Valve | Brass |
| Air Chamber | Aluminum |
Rubber – 617 lpm (163 gpm)
TPE – 613 lpm (162 gpm)
PTFE – 534 lpm (141 gpm)
8.6 bar (125 psi)
6.4 mm (1/4'')
Rubber – 2.69 L (0.71 gal)
TPE – 2.8 L (0.74 gal)
PTFE – 1.51 L (0.40 gal)
