Hot selling models T15/AAAAB/BNS/BN/BN T15/AAAAB/BNS/BN/BN/0014 T15/AAAAB/NES/NE/NE/0014 T15/AAAAB/NEU/NE/NE/0014 T15/AAAAB/TWS/TF/ATF/0014 T15/AAAAB/VTS/VT/VT/0014 T15/AAAAB/ZWS/WF/WF/0014 T15/AAAPB/ZWS/WF/WF/0014 T15/SSAAB/TWS/TF/STF/0014 T15/WWAAB/BNS/BN/BN/0014 T15/WWAAB/NES/NE/NE/0014 T15/WWAPB/BNS/BN/BN/0014 TZ15/AAAAB/BNS/BN/BN/0014 TZ15/AAAAB/NES/NE/NE/0014 TZ15/AAAAB/TNU/TF/ATF TZ15/AAAAB/TNU/TF/ATF/0014 TZ15/AAAAB/VTS/VT/VT TZ15/AAAAB/ZWS/WF/WF/0014 TZ15/SSAAB/BNS/BN
3/4" FNPT
76 mm (3")
76 mm (3")
NPT/BSPT (Threaded)
Rubber – 5.5 m(18') Dry9.45m(31') Wet
TPE – 3.49 m (13') Dry, 8.53 m (28') Wet
PTFE – 3.49 m (13') Dry, 8.53m (28')Wet
Note: Dimensions vary by material and connection. For additional information, please refer to the T15 Metal Manual.
Note: Additional performance curves can be found in the T15 Metal Manual.
3/4" FNPT
76 mm (3")
76 mm (3")
NPT/BSPT (Threaded)
Rubber – 878 lpm (232 gpm)
TPE – 845 lpm (223 gpm)
PTFE – 704 lpm (186 gpm)
8.6 bar (125 psi)
10 mm (3/8'')
Rubber – 5.5 m (18') Dry, 9.45 m (31') Wet
TPE – 3.49 m (13') Dry, 8.53 m (28') Wet
PTFE – 3.49 m (13') Dry, 8.53 m (28') Wet
Rubber – 5.3 L (1.40 gal)
TPE – 5.4 L (1.43 gal)
PTFE – 3.6 L (0.95 gal)
| MATERIAL | SHIP WEIGHT |
|---|---|
| Aluminum | 53 kg (116 lb) |
| Cast Iron | 91 kg (200 lb) |
| DESCRIPTION | MATERIAL |
|---|---|
| Center Block | Aluminum, Polypropylene |
| Air Valve | Brass |
| Air Chamber | Aluminum |
Rubber – 878 lpm (232 gpm)
TPE – 845 lpm (223 gpm)
PTFE – 704 lpm (186 gpm)
8.6 bar (125 psi)
10 mm (3/8'')
Rubber – 5.3 L (1.40 gal)
TPE – 5.4 L (1.43 gal)
PTFE – 3.6 L (0.95 gal)
