Item: 01-10725 Model: P1/AALLL/VTS/VT/ATF/0014 Series: Pro-Flo Wetted material: Aluminum Diaphragm material: FKM Fluid connections: 1/2-inch BSPT Inlet / discharge: Center Swivel / Center Swivel
WILDEN / PRO-FLO SERIES
This Pro-Flo air-operated double-diaphragm pump combines an aluminum wetted housing with FKM diaphragms. The clamped configuration has 1/2-inch BSPT fluid connections and an acetal air-side assembly.
Complete model
P1/AALLL/VTS/VT/ATF/0014
FLUID CONNECTION
1/2-inch BSPT
MAXIMUM FLOW
≈ 58.7 L/min
MAXIMUM PRESSURE
125 psig
| Brand / item number | WILDEN / 01-10725 |
|---|---|
| Pump series | Pro-Flo |
| Nominal fluid port size | 1/2 in (0.5 in) |
| Construction | Clamped |
| Wetted housing | Aluminum |
| Diaphragm material | FKM |
| Diaphragm design / stroke | Traditional / Full-Stroke |
| Check ball material | FKM |
| Valve seat material | Aluminum |
| Connection standard | BSPT threaded |
| Inlet / discharge orientation | Center Swivel / Center Swivel |
| Maximum flow | 15.5 US gpm (approximately 58.7 L/min) |
|---|---|
| Maximum operating pressure | 125 psig (approximately 8.6 bar) |
| Maximum air supply pressure | 125 psig (approximately 8.6 bar) |
| Maximum solids diameter | 0.06 in (approximately 1.5 mm) |
| Listed dry suction lift | 19 ft (approximately 5.79 m) |
| Listed wet suction lift | 31 ft (approximately 9.45 m) |
| Listed operating temperature | 40–180 °F (approximately 4.4–82.2 °C) |
| Self-priming | TRUE |
| Listed shipping weight | 11.5 lb (approximately 5.22 kg) |
Maximum flow and maximum pressure are separate ratings. Check the duty point, fluid compatibility, temperature and suction conditions for the complete pump configuration.
| Air-side material | Acetal |
|---|---|
| Outer pistons | Aluminum |
| Wetted O-rings / gaskets | PTFE |
| Muffler | Plastic |
| Air inlet connection | 1/4" NPT |
| Inlet / discharge size | 1/2 in / 1/2 in |
| Thread standard | BSPT |
| Construction detail code | 0014 |
AIR REPAIR KIT
Air distribution service kit for this 1/2-inch Pro-Flo P1 configuration with a plastic air valve. Confirm the complete pump code when ordering.
WET-END REPAIR KIT
Wetted-end service kit for this 1/2-inch clamped metal pump with FKM diaphragms (VTS). Match the installed elastomers and full pump model.
Repair kits are ordered separately. Include the complete pump code and kit number in your enquiry.
Quote 01-10725 and P1/AALLL/VTS/VT/ATF/0014, together with quantity, fluid, operating temperature, required flow and discharge pressure. For individual replacement parts, include the component number and a clear pump nameplate photo.
