Item: 02-12189 Model: XPX220/SSAAA/VTS/VT/SVT Series: Pro-Flo X Wetted material: Stainless steel Diaphragm material: FKM Nominal fluid port size: 1-inch Construction: Bolted
WILDEN / PRO-FLO X SERIES
This 1-inch Pro-Flo X air-operated double-diaphragm pump uses stainless steel wetted housing and FKM diaphragms. Its bolted construction is identified by the complete ordering code below.
Complete model
XPX220/SSAAA/VTS/VT/SVT
FLUID PORT SIZE
1-inch
| Brand / item number | WILDEN / 02-12189 |
|---|---|
| Pump series | Pro-Flo X |
| Nominal fluid port size | 1 in |
| Construction | Bolted |
| Wetted housing | Stainless steel |
| Diaphragm material | FKM |
| Check ball material | FKM |
| Valve seat material | Stainless steel |
| Outer pistons | Stainless steel |
|---|---|
| Wetted O-rings / gaskets | PTFE-encapsulated FKM |
AIR REPAIR KIT
Air distribution service kit matched to this 1-inch Pro-Flo X XPX220 configuration. Confirm the complete pump code when ordering.
WET-END REPAIR KIT
Wetted-end service kit matched to this 1-inch bolted pump with FKM diaphragms. Match the installed elastomers and full ordering code.
Repair kits are ordered separately. Include the complete pump code and kit number in your enquiry.
Quote 02-12189 and XPX220/SSAAA/VTS/VT/SVT, together with quantity, fluid, operating temperature, required flow and discharge pressure. For replacement parts, include the component number and a clear pump nameplate photo.
