Item: S02-0024 Model: TZ2/SSAAB/VTS/VT/STF/0014 Series: Turbo-Flo Z Wetted material: Stainless steel Diaphragm material: FKM Nominal fluid port size: 1-inch Construction: Clamped
WILDEN / TURBO-FLO Z SERIES
This 1-inch Turbo-Flo Z air-operated double-diaphragm pump uses stainless steel wetted housing and FKM diaphragms. Its clamped construction is identified by the complete ordering code below.
Complete model
TZ2/SSAAB/VTS/VT/STF/0014
FLUID PORT SIZE
1-inch
| Brand / item number | WILDEN / S02-0024 |
|---|---|
| Pump series | Turbo-Flo Z |
| Nominal fluid port size | 1 in |
| Construction | Clamped |
| Wetted housing | Stainless steel |
| Diaphragm material | FKM |
| Check ball material | FKM |
| Valve seat material | Stainless steel |
| Outer pistons | Stainless steel |
|---|---|
| Wetted O-rings / gaskets | PTFE |
| Special option code | 0014 |
Quote S02-0024 and TZ2/SSAAB/VTS/VT/STF/0014, together with quantity, fluid, operating temperature, required flow and discharge pressure. For replacement parts, include the component number and a clear pump nameplate photo.
