WILDEN Pneumatic Diaphragm Pump, 1/2" Plastic Diaphragm Pump, 01-11063 P100/PPPPP/TEU/TF/PTV The diaphragm pump adopts the design of unbalanced air valve, no dead center, stable operation; Plastic self-lubricating air system eliminates the need for lubrication, reducing maintenance costs and pollution risks. The special and fast exhaust structure ensures that the air valve does not freeze and improves the air utilization rate. It has excellent applications in the chemical field.
1/4" FNPT
13 mm (1/2")
13 mm (1/2")
NPT/BSPT (Threaded)
Rubber – 5.2 m (17.0') Dry, 8.7 m (28.4') Wet
TPE – 5.2 m (17.0') Dry, 5.5 m (18.0') Wet
PTFE – 4.5 m (14.7') Dry, 9.3 (30.6') Wet
Note: Dimensions vary by material and connection. For additional information, please refer to the P100 Plastic Manual.
Note: Additional performance curves can be found in the P100 Plastic Manual.
1/4" FNPT
13 mm (1/2")
13 mm (1/2")
NPT/BSPT (Threaded)
Rubber – 56 lpm (14.8 gpm)
TPE – 58.7 lpm (15.5 gpm)
PTFE – 57 lpm (15 gpm)
8.6 bar (125 psi)
1.6 mm (1/16")
Rubber – 5.2 m (17.0') Dry, 8.7 m (28.4') Wet
TPE – 5.2 m (17.0') Dry, 5.5 m (18.0') Wet
PTFE – 4.5 m (14.7') Dry, 9.3 (30.6') Wet
Rubber – 0.10 L (0.027 gal)
TPE – 0.11 L (0.029 gal)
PTFE – 0.10 L (0.027 gal)
| Material | Ship Weight |
|---|---|
| Polypropylene / Conductive Polypropylene | 4 kg (8 lb) |
| PVDF / Conductive PVDF | 5 kg (10 lb) |
| Description | Material |
|---|---|
| Center Section | Polypropylene, Conductive Polypropylene |
| Air Valve | Polypropylene, Conductive Polypropylene |
Rubber – 56 lpm (14.8 gpm)
TPE – 58.7 lpm (15.5 gpm)
PTFE – 57 lpm (15 gpm)
8.6 bar (125 psi)
1.6 mm (1/16")
Rubber – 0.10 L (0.027 gal)
TPE – 0.11 L (0.029 gal)
PTFE – 0.10 L (0.027 gal)
