Item: S02-12951 Model: TZ2/AAAAB/NES/NE/ABN Series: Turbo-Flo Z Wetted material: Aluminum Diaphragm material: neoprene Nominal fluid port size: 1-inch Construction: Clamped
WILDEN / TURBO-FLO Z SERIES
This 1-inch Turbo-Flo Z air-operated double-diaphragm pump uses aluminum wetted housing and neoprene diaphragms. Its clamped construction is identified by the complete ordering code below.
Complete model
TZ2/AAAAB/NES/NE/ABN
FLUID PORT SIZE
1-inch
| Brand / item number | WILDEN / S02-12951 |
|---|---|
| Pump series | Turbo-Flo Z |
| Nominal fluid port size | 1 in |
| Construction | Clamped |
| Wetted housing | Aluminum |
| Diaphragm material | neoprene |
| Check ball material | neoprene |
| Valve seat material | Aluminum |
| Outer pistons | Aluminum |
|---|---|
| Wetted O-rings / gaskets | Buna-N |
Quote S02-12951 and TZ2/AAAAB/NES/NE/ABN, together with quantity, fluid, operating temperature, required flow and discharge pressure. For replacement parts, include the component number and a clear pump nameplate photo.
